Complementary N+P MOSFETs
|
Part Number
|
Data
Sheet |
Package
|
Polarity
|
Config.
|
VDS
Max (V) |
VGS
Max (+/-V) |
VGS(th)
Min (V) |
VGS(th)
Max (V) |
ID
Max (A) |
PD
(W) |
RDS(on)
Max @ VGS=10V (mΩ) |
RDS(on)
Max @ VGS=4.5V (mΩ) |
RDS(on)
Max @ VGS=2.5V (mΩ) |
| SSFB12N05 |  |
DFN2x2 | N+P | Dual | 12 -12 |
12 12 |
0.4 -0.4 |
1.0 -1.0 |
5.0 -5.0 |
1.9 1.9 |
- | 32 74 |
42 110 |
| SSFB8116 | |
DFN2x3 | N+P | Dual | 20 -20 |
10 10 |
0.3 | 1.0 -1.0 |
3.8 -2.5 |
1.25 1.25 |
- | 40 90 |
55 130 |
| GSFN8116 | |
PPAK2x3 | N+P | Dual | 20 -20 |
10 10 |
0.3 -0.3 |
1 -1 |
3.8 -2.5 |
1.25 1.25 |
- | 40 100 |
56 140 |
| GSFN03C10 | |
PPAK3x3 | N+P | Dual | 30 -30 |
20 20 |
1.2 -1.2 |
2.5 -2.5 |
10 -7 |
2.5 2.5 |
13 32 |
18 49 |
- |
| GSFN3703 | |
PPAK3x3 | N+P | Dual | 30 -30 |
20 20 |
1.2 -1.2 |
2.5 -2.5 |
12 -16 |
20 20 |
20 18 |
30 30 |
- |
| GSFN3712 | |
PPAK3x3 | N+P | Dual | 30 -30 |
20 20 |
1.2 -1.2 |
2.5 -2.5 |
12.0 -8.0 |
20 20 |
20 50 |
30 75 |
- |
| GSFQ0744 | |
SOP-8 | N+P | Dual | 100 -100 |
20 20 |
1.2 -1.2 |
2.5 -2.5 |
2.1 -1.7 |
1.47 1.47 |
175 290 |
170 340 |
- |
| GSFQ4701 | |
SOP-8 | N+P | Dual | 40 -40 |
20 20 |
1.0 -1.0 |
2.5 -2.5 |
6.7 -7.2 |
2.5 2.5 |
32 40 |
45 60 |
- |
| GSFQ6701 | |
SOP-8 | N+P | Dual | 60 -60 |
20 20 |
1.2 -1.2 |
2.5 -2.5 |
5.9 -4.7 |
2.01 2.01 |
30 48 |
36 68 |
- |
| GSFQ6710 | |
SOP-8 | N+P | Dual | 60 -60 |
20 20 |
1.2 -1.0 |
2.5 -2.5 |
4.5 -3.5 |
3.57 3.57 |
54 105 |
63 145 |
- |
| SSFQ1006S | |
SOP-8 | N+P | Dual | 20 -20 |
12 12 |
0.5 -0.5 |
1.0 -1.0 |
10 -6 |
2 2 |
- | 14 45 |
18 60 |
| SSFQ3710 | |
SOP-8 | N+P | Dual | 30 -30 |
20 20 |
1.2 -1.0 |
2.5 -2.5 |
10 -6.5 |
5.0 5.0 |
13 30 |
18 46 |
- |
| SSFQ3712 | |
SOP-8 | N+P | Dual | 30 -30 |
20 20 |
1.2 -1.2 |
2.5 -2.5 |
8.0 -5.5 |
2.5 2.5 |
20 50 |
30 90 |
- |
| SSFQ4614 | |
SOP-8 | N+P | Dual | 40 -40 |
20 20 |
1 -1 |
2 -2 |
8 -7 |
2 2 |
19 35 |
29 45 |
- |
| SSF2116 | |
SOT-23-6L | N+P | Dual | 20 -20 |
10 10 |
0.3 -0.3 |
1 -1 |
3.8 -2.5 |
1.25 1.25 |
- | 40 100 |
55 140 |
| SSF3714 | |
SOT-23-6L | N+P | Dual | 30 -30 |
20 20 |
1.2 -1.2 |
2.5 -2.2 |
4 -3 |
2.0 | 30 65 |
46 90 |
- |
| SSF6602 | |
SOT-23-6L | N+P | Dual | 30 -30 |
20 20 |
1.2 -1.0 |
2.2 -2.5 |
3.5 -2.7 |
1.2 1.2 |
58 100 |
95 150 |
- |
| SSF8120 | |
SOT-23-6L | N+P | Dual | 20 -20 |
8 8 |
0.3 -0.3 |
1.0 -1.0 |
1.45 -1.0 |
1.0 1.0 |
- | 300 600 |
400 850 |
| GSFK3420 | |
SOT-363 | N+P | Dual | 30 -30 |
12 12 |
0.5 -0.5 |
1.2 -1.2 |
0.8 -0.4 |
0.275 0.275 |
- | 450 1000 |
650 1600 |
| SSFK9120 | |
SOT-363 | N+P | Dual | 20 -20 |
8 8 |
0.3 -0.3 |
1.0 -1.0 |
0.8 -0.4 |
0.275 0.275 |
- | 300 600 |
400 850 |
| SSF2120Y | |
SOT-563 | N+P | Dual | 20 -20 |
8 8 |
0.3 -0.3 |
1.0 -1.0 |
0.8 -0.4 |
0.312 0.312 |
- | 300 600 |
400 850 |
| SSF7120 | |
SOT-563 | N+P | Dual | 20 -20 |
12 12 |
0.3 -0.3 |
1.0 -1.0 |
0.8 -0.4 |
0.312 0.312 |
- | 300 600 |
400 850 |
| GSFD03C16 | |
TO-252-4L | N+P | Dual | 30 -30 |
20 20 |
1.2 -1.0 |
2.5 -2.5 |
16 -12 |
32.5 32.5 |
12 30 |
18 46 |
- |
| GSFD04C16 | |
TO-252-4L | N+P | Dual | 40 -40 |
20 20 |
1.2 -1.2 |
2.5 -2.5 |
15 -12 |
20 20 |
32 40 |
42 52 |
- |
| GSFD06C20 | |
TO-252-4L | N+P | Dual | 60 -60 |
20 20 |
1.2 -1.2 |
2.5 -2.5 |
19 17 |
20.1 20.1 |
30 48 |
36 68 |
- |
| SSF2145CH6 | |
TSOP-6 | N+P | Dual | 20 -20 |
8 8 |
0.4 -0.4 |
1 -1 |
4.8 -2.9 |
1.7 1.7 |
- | 55 80 |
75 100 |
